- This jewelry welding machine is suitable for: gold, silver, copper, general alloy steel, stainless steel, high toughness aluminum alloy, copper alloy, beryllium copper, red copper and very hard alloy materials. Mainly used in jewelry processing and manufacturing, gold and silver jewelry repair and processing shop, and so on
- Features :
- 7 “FTF true color touch screen, user-friendly interface simple and easy to operate.7 inch TFT true color touch screen, parameter setting and CCD monitor integrated .
- the output waveform can be set as monopulse, trapezoidal wave, rectangular wave, etc., due to the processing needs of various materials.
- the output parameters can be set as current C, pulse width P, frequency F and other parameters due to the processing requirements of material thickness.
- PWM modulation light, fast speed PI adjustment, output single spot power stable and reliable .
- 4 groups of dynamic, static selection.
- electric water filling function, high and low temperature alarm function of water tank .
- hd microscope & CCD observation system.
Technical Specifications
Laser type | Nd. YAG |
Machine weight | 220 K.g |
Machine Dimensions | 120cm L * 138 cm W * 70 cm H. |
Positioning way | Red Light |
Laser power | 200 W |
Max Weld Depth | 0.9 mm |
Input source | 220 V |
Cooling method | External chiller |
Visual system and control | CCD touch screen TO show options and Parameters, microscope |
The price includes the Standard specifications only .
