DTF Textile Printer

Description

The DTF printer delivers high-performance fabric printing, making it a top choice for large-scale production. It produces vibrant, high-resolution prints with rich white ink that offers excellent coverage on both light and dark textiles. With smooth color transitions and long-lasting results, this printer is ideal for businesses looking to achieve professional-grade fabric prints.

From the following options, select the machine specifications that suit your needs.

Technical parameter

Technical Parameter

Operating & Drying Systems

Power & Energy Consumption

Dimensions & Weight

- Model: E6502.

- Printing Technology: Epson 3200-A1 Printhead.

- Number of Printheads: 2.

- Printing Height: Adjustable between 1.5 mm and 2.5 mm.

- Printhead Maintenance: Fully automatic system including anti-clogging, flash spray, and auto-moisturizing features to maintain optimal performance.

- Ink Type: Pigment-based Ink.

- Ink Colors: CMYMK + White.

- Ink Tank Capacity: 1500 ml per color.

- Ink Supply System: Pressure-controlled magnetic pump for consistent ink flow.

- Max Print Width: 650 mm.

- Compatible Media: Heat transfer PET film.

- Max Roll Weight: Less than 40 kg.

- Drying System:
Integrated powder shaker drying mechanism for efficient curing .

- User Interface Languages: Chinese / English .

- Supported Operating Systems: Windows 10 / Windows 11 .

- Operating Environment:
- Temperature: 18°C to 25°C .

- Humidity: 35% to 65% .

- Connectivity:
Gigabit Ethernet port for high-speed data transfer.

- Network Compatibility: Supports LAN printing.

- RIP Software:
Compatible with Photoprint for precise color management and output.

- Power Specifications: AC 220V, 50Hz / 60Hz.

- Power Usage:
- Standby Mode: Approximately 6W .
- Maximum Consumption: Up to 1200W.

- Noise Levels:
- Idle: Below 32 dB.
- During Operation: Below 65 dB.

- Machine Size:
1480 mm (L) × 560 mm (W) × 1365 mm (H).

- Net Weight: 170 kg .

- Packaging Dimensions:
1540 mm (L) × 750 mm (W) × 835 mm (H).
