HYDRAULIC CNC PRESS BRAKE WE67K-SMART

HARSLE ELECTRO-HYDRAULIC CNC PRESS BRAKE

RIGID FRAME CONSTRUCTION & DUAL HYDRAULIC CYLINDERS

The foundation of every HARSLE press brake is a solid, mono-block frame made from mill-certified, high-yield steel. As a result, our press brakes perform accurately and reliably year after year. We’re so confident in our frames that we offer a 10-year warranty with our standard machines.
Dual hydraulic cylinders located on either side Of the
ram provide faster approach speeds. The cylinders
are synchronized to provide smooth motion resulting
in precise ram positions to accuracies of .0004″

WIDE FRAME STANCE

HARSLE made press brakes can easily accommodate parts with deep bends and that require long tooling because of our open space design. Our machines typically deeper throat depths. larger daylight spaces and longer stroke lengths than any manufacturer in the market.
We’ve also mounted the RAM GUIDING on the outside of the frame to maximize the distance between the side frames allowing our brakes to accommodate deep part flanges.

BACK GAUGE SYSTEMS

The correct back gauge for the application can have a substantial positive influence on production part volume and accuracy. The more intricate the parts. typically the more axes on the back gauge you should have. Volume of parts needs to be considered also. A smart, experienced brake press operator can bend, form and produce some very intricate parts without even a single axis back gauge. However, the more time it takes to form the correct part, the more costs you have in the part. So the best scenario would be to have an experienced operator with the correct back gauge system that will magnify their skills. But today’s market. smart, experienced Press Brake operators are getting hard to find. So the correct back gauge for the application will decrease costs per part by helping to make a good press operator, a great one. The less experience an operator is the more axes you should have. Also. experienced operators know the benefit of correct back gauge for applications. HARSLE is here to consult with you on your application requirements.

CROWNING SYSTEMS

Manual and CNC crowning ensures a constant bend angle across the full length of the-machine.

This is achieved by pre loading the machine. to offset any possible deflection under load or compensate for any tool wear, so that under load contacting surfaces are parallel each other.

With CNC crowning systems the press brake control is preprogrammed with machine characteristics and deflection data. With manual crowning a simple spread-sheet or chart can be easily developed for each application.

Machine Details

Segmented Bending Toolings
Extremely fast press brake tooling
changes.

Front Arms
Movable in different directions.

Fast Clamps

Extremely accurate clamping, positioning and alignment.

Proportional Valve

Rexroth from Germany

EMB Tubing connector

Good-looking structure and reduce the possibility of oil leakage.

Schneider Electric Components

High-quality electric parts can perform well even the electricity is not stable and customers can easily get the replacement anywhere in the world.

SIEMENS Motor
German famous brand motor improves the lifespan of the and keeps the machine working in low noise environment.

Servo motor
From world famous brand YASKAWA,
working fastly with high accuracy.

KACON Foot Switch

South Korea brand foot switch ismovable
and can stop the machineany time by the
emergency button.

Ball Screw and Linear Guide

HIWIN From Taiwan.

Back Light Curtain

A protective device on each side can protect the user during operation.

Linear Encoder
Spanish FAGOR can get high
performance.

Hydraulic Valve

Rexroth from Germany

Z stopper

Fine adjustment with high accuracy up
to ±0.02mm.
